32-bit ARM Assembly Basics: Part III - The Calling Convention

Posted on April 02, 2021

Function basics

Before we jump right into specifics of calling functions, let's uncover the purposes of the last two registers that we need.

The Program Counter - pc

The program counter register holds the address of the instruction to be executed. It is basically a pointer. That means we could change the flow of the program by modifying it directly. This is ill-advised and we should use control-flow instructions which reduce the possibility of an error.

Every instruction modifies the pc register as a side effect. On every instruction, a number of bytes that were occupied by this instruction are added to the pc implicitly. Because of that our program has natural execution flow.

mov r0, #1 /* pc += 4; r0 = 1 */

We can also manually cause a jump just to a given address like in the example below.

        mov r0, #1
        mov r0, #2
        mov r0, #3
        ldr pc, =label
        mov r0, #4
        mov r0, #5
    label:
        mov r0, #6

        /* We end up with six in r0 */

The Frame Pointer - fp

The frame pointer points to the area of the stack before any allocation has been made. This area is called a stack frame or sometimes call frame.

A frame pointer is static during the procedure call, i.e., it does not change as opposed to the stack pointer. This makes it much easier to access local variables that we have allocated on the stack because we don't need to take into account how sp was changing, we just use the fp.

It points at the top of the previous stack frame. So we can add to it to access values from the parent (caller) function. We can subtract from it to access anything that is allocated by the callee. The thing is this is only how the frame pointer is supposed to be used. We have to do it ourselves.

The image shows what sp, fp, and stack look like before making a call and after making a call.

As you can see the frame pointer gives us easy access to our stack (for our variables) and the caller stack (which might hold additional arguments passed to the callee).

Okay, I omitted something. I believe that the frame pointer is most often gonna be set to the address a little bit above the caller's stack pointer. This is due to the fact that we need to save (push) the old frame pointer value before we can set a new value for the frame pointer. It is easier this way because we don't need to use registers to first push the fp to some register, set fp to sp, then take value from that register and push it onto the stack. We can avoid storing fp in the register if we push it onto the stack in the first step and then assign sp to fp. We just need to change our initial assumption that fp points to the beginning of the callee stack. Instead, it will point two the beginning minus eight bytes (eight because we need to push two values to keep alignment, and we have push lr anyway).

So this picture might be more realistic.

In our assembly it would look as follows.

f:
    // prelude, i.e., save frame pointer and return address
    push {fp, lr}
    mov fp, sp // set our frame pointer, so have a static address
               // from which we can access other values on the stack

    // function steps

    // optionally we could call here `mov sp, fp` as  to deallocate the
    // stack, but I think this is unnecessary if we used `pop` properly
    pop {fp, lr}
    bx lr

The Calling Convetion

Now that we know how the most crucial registers are used, let us combine all our knowledge and explain conventions behind functions in ARM32 assembly.

Arguments and return value

The r0-r3 registers are also called arguments registers. In these, we can pass four word-sized parameters to the callee. If we want to pass more arguments to the function we need to use the stack.

So if the function would need to take five arguments, before the call we would set registers r0-r3 accordingly, and push one value onto the stack.

mov r0, #0
mov r1, #1
mov r2, #2
mov r3, #3
mov r4, #4
push {r4, ip} // ip just to keep stack aligned
bl some_func
pop {r4, ip} // although we could just deallocate (wihout storing in register)
             // using `add sp, sp, #8`

As for the return value we always expect it to be place in the r0 register.

Register convetions

When we call some function some registers are expected to not change during that call, i.e., the called function should not affect them, at least from the perspective of a caller. To be precise it can change them but before returning it should recreate their state before the call. With other registers, the called function can do whatever it wants, and we cannot assume anything about what is going to be left in these registers after calling a function.

These concepts are called call-preserved and call-clobbered respectively. Or another way: callee-saves and caller-saves. So which registers fall under which category?

Remember then, if you define a new function and intend to use any register from a call-preserved category, save them before usage on the stack, and bring them back to their original state before returning. On contrary, if you call some function and you rely on the call-clobbered registers, make sure to store them, before calling this function, because it might replace them with some garbage.

Defining a function

To sum it up let's go back to our original hello world code, and go over it.

/* Hello-world program.     Print "Hello, assembly!" and exit with code 0. */
.data
    hello:
        .string "Hello, assembly!\n"

.text
    .global main
    main:
        push {ip, lr}
        ldr r0, =hello
        bl printf

        mov r0, #2 // put 2 in `r0`
        mov r1, r0 // copy 2 from `r0` to `r1`
        sub r0, r0, r1 // put 0 in `r0` by subtracting `r1` from `r0`

        pop {ip, lr}
        bx lr

This is a very simple function. Inside we call a different function, the printf. Because of that at the beginning, we push lr onto the stack, because it is in the call-clobbered category, and we need it at the end of our function in order to return to the caller of main. Next, we put the address of our "Hello, asembly!" string into r0 register. r0 is used as an argument for the printf function. Then we to some simple arithmetic just for kicks. In the end, we restore the lr value and jump to the address in it. Yay, we can read the whole file now!

Now let's define a function that takes five numbers, sums them and prints the result.

.data
    sum_message:
        .string "The sum is %u\n"
.text
    sum_five:
        // prelude, i.e., save frame pointer and return address
        push {fp, lr}
        mov fp, sp

        add r0, r0, r1
        add r0, r0, r2
        add r0, r0, r3
        ldr r3, [fp, #8] // We get the last argument from from the
                         // previous call stack
        add r0, r0, r3

        pop {fp, pc}

    .global main
    main:
        // prelude, i.e., save frame pointer and return address
        push {fp, lr}
        mov fp, sp // set our frame pointer, so have a static address
        // from which we can access other values on the stack

        // prepare arguments to sum up
        mov r0, #0
        mov r1, #1
        mov r2, #2
        mov r3, #3
        mov r4, #4
        push {r4, ip}

        bl sum_five
        add sp, sp, #8 // deallocate the stack

        mov r1, r0 // put number to print in `r1`
        ldr r0, =sum_message // put address of the string with format to
                             // print in `r0`
        bl printf

        pop {fp, lr}
        bx lr

In the main function, we put the first four arguments in the r0-r3 registers. We put the additional argument onto the stack using push. Then we call the sum_five function which saves fp and sp (although we don't call any function so this is kind of unnecessary here). We add values from the registers and load the last argument using the frame pointer with a relative offset of eight bytes. We sum all this in r0 which is used to store return values. The rest is easy, we return, we call printf and return from main.

Conclusions

I hope I got everything right. I know I have been omiting some details like how arguments of a size different than word should be passed etc., so I still don't know how much of the stuff works, I must say that I am capable now of reading the ARM32 assembly and even writing some of my own which makes me very happy. I would advise any other than myself to read this series that I made because there are plenty of others much better prepared tutorials.

I was using two books to get the basics that I laid out in this series.

• "Compiling to Assembly" by Vladimir Keleshev
• "Introduction to Compilers and Language Design" by Douglas Thain

Both these books are great and go over things in more detail. Anyway, thanks for reading!
